Features
- Class-A headphone amplification
- Alps Blue Velvet volume control
- Reed relay input selection
- Ceramic insulators for the power transistors
- Galvanically isolated microprocessor control section
- Microphonic-isolating PCB mounts
Specifications
Inputs
MM RCA phono input: 47 kΩ parallel 470 pF input impedance, suitable for 5 mV cartridges
Line-level inputs: 130 mV sensitivity, 47 kΩ input impedance, suitable for 2V
Power amp in:Â DIN Socket
Outputs
Powered accessory sockets:Â +24 V for Naim phono amplifier
Speaker outputs (4 mm sockets): 80 W per channel into 8 Ω, 130 W per channel into 4 Ω
Line outputs, variable: Pre-amp (DIN), bi-amp (DIN), sub (RCA pair) 775 mV, <50 Ω
Line outputs, fixed: AV (DIN), stream (DIN) 130 mV, 600 Ω
Headphone output:Â 1/4 inch (6.35 mm) TRS Socket
Power
Power consumption, max: 400 VA
Power consumption, quiescent:Â 37Â VA
Physical
Shipping weight:Â 38 lb
Shipping dimensions: 9.4″ x 23.2″ x 19.6″
Weight:Â 14 kg
Dimensions (HWD):Â 3.4″ x 17″ x 12.4″
